1
Sextavado
interno
3
Estriado
Unit Drive interno
9
perfil Torx®
interno
Surface Drive
interno
7
perfil Torx®
externo
7
þ
perfil Torx®
externo abaulado
ĩ
perfil Torx® Plus
externo
?
Fenda simples
externo
;
Fenda cruzada (PH)
externo
5
Hexagonal
externo
5
ÿ
Hexagonal
externo abaulado
P E R F I S
D E
T R A B A L H O
110
3
SOQUETES E ACESSÓRIOS
b
Torx® e Torx Plus® marcas registradas da Acument Intellectual Properties, LLC. USA (antiga Camcar Textron)
20 L
Soquete sextavado longo 1/4”
R1
4 - 13
!
3/16”- 1/2”
"
DIN 3124, ISO 2725-1
Aço Gedore-Vanadium. Niquelado e cromado. Parede fina. Para
trabalhar com acessórios manuais com encaixe
a
6,35 mm (1/4”),
conforme DIN 3120 - C 6.3, ISO 1174. Facilita trabalhos com peque-
nos parafusos sextavados. Modelo longo.
Código
Ref.
$
L
mm
d1
mm
d2
mm
t
mm
/
013.521
20 L - 4 mm
50
6,9
12,0
3,0
17
013.522
20 L - 4,5 mm
50
7,5
12,0
3,4
17
013.523
20 L - 5 mm
50
8,2
12,0
3,7
18
013.524
20 L - 5,5 mm
50
8,8
12,0
4,5
19
013.525
20 L - 6 mm
50
9,4
12,0
5,2
20
013.526
20 L - 7 mm
50
11,0
12,0
6,0
24
013.527
20 L - 8 mm
50
12,0
12,0
7,5
27
013.528
20 L - 9 mm
50
13,0
13,0
7,5
30
013.529
20 L - 10 mm
50
14,7
14,7
9,0
33
013.530
20 L - 11 mm
50
16,0
16,0
10,5
47
013.531
20 L - 12 mm
50
17,0
17,0
12,0
50
013.532
20 L - 13 mm
50
18,5
18,5
12,0
54
Código
Ref.
%
L
mm
L
mm
d1
mm
d2
mm
t
mm
013.551
20 L - 3/16”
50
7,8
12,0
3,7
16
013.552
20 L - 7/32”
50
8,8
12,0
4,5
17
013.553
20 L - 1/4”
50
9,8
12,0
5,2
17
013.554
20 L - 9/32”
50
11,0
12,0
6,0
22
013.555
20 L - 5/16”
50
12,0
12,0
7,5
25
013.556
20 L - 11/32”
50
13,0
13,0
7,5
29
013.557
20 L - 3/8”
50
14,0
14,0
9,0
33
013.558
20 L - 7/16”
50
16,0
16,0
10,5
43
013.559
20 L - 1/2”
50
18,0
18,0
12,0
54
Soquetes,
chaves soquete, catracas e acessórios manuais, jogos
Aço especial Gedore de alta resistência. Grande diversidade
de perfis que facilitam o trabalho com pequenos parafusos.
Encaixe
a
6,35 mm (1/4”).
Rb
20
Soquete sextavado 1/4”
R1
4 - 14
!
3/16”- 9/16”
"
DIN 3124, ISO 2725-1
Aço Gedore-Vanadium. Niquelado e cromado. Parede fina. Para
trabalhar com acessórios manuais com encaixe
a
6,35 mm (1/4”),
conforme DIN 3120 - C 6.3, ISO 1174. Facilita trabalhos com pe-
quenos parafusos sextavados. Modelo curto.
Código
Ref.
$
L
mm
d1
mm
d2
mm
t
mm
/
013.001
20 - 4 mm
25
6,9
12,0
2,0
9
013.002
20 - 4,5 mm
25
7,5
12,0
2,3
10
013.003
20 - 5 mm
25
8,2
12,0
2,5
10
013.004
20 - 5,5 mm
25
8,8
12,0
3,0
10
013.005
20 - 6 mm
25
9,4
12,0
3,5
10
013.006
20 - 7 mm
25
11,0
12,0
4,0
11
013.007
20 - 8 mm
25
12,0
12,0
5,0
14
013.008
20 - 9 mm
25
13,0
13,0
5,0
16
013.009
20 - 10 mm
25
14,7
14,7
6,0
18
013.010
20 - 11 mm
25
16,0
16,0
7,0
25
013.011
20 - 12 mm
25
17,0
17,0
8,0
29
013.012
20 - 13 mm
25
18,5
18,5
8,0
30
013.013
20 - 14 mm
25
19,7
19,7
10,0
37
Código
Ref.
%
L
mm
d1
mm
d2
mm
t
mm
/
013.051
20 - 3/16”
25
7,8
12,0
2,5
9
013.052
20 - 7/32”
25
8,8
12,0
3,0
9
013.053
20 - 1/4”
25
9,8
12,0
3,5
25
013.054
20 - 9/32”
25
11,0
12,0
4,0
10
013.055
20 - 5/16”
25
12,0
12,0
5,0
13
013.056
20 - 11/32”
25
13,0
13,0
5,0
15
013.057
20 - 3/8”
25
14,0
14,0
6,0
18
013.058
20 - 7/16”
25
16,0
16,0
7,0
23
013.059
20 - 1/2”
25
18,0
18,0
8,0
29
013.060
20 - 9/16”
25
20,0
20,0
10,0
36
