SOQUETES E ACESSÓRIOS
e
32
Soquete sextavado 3/4”
U1
17 - 60
!
3/4”- 2”
"
DIN 3124, ISO 2725-1
Aço Gedore-Vanadium. Niquelado e cromado. Para trabalhar com
acessórios manuais com encaixe
a
19,05 mm (3/4”), conforme
DIN 3120 - C 20, ISO 1174. Modelo curto.
Código
Ref.
$
L
mm
d1
mm
d2
mm
t
mm
/
017.400
*
32 - 17 mm
55
33,2
35,3
12,5
240
017.420
*
32 - 18 mm
51,5
28,3
36,0
19,0
220
017.401
*
32 - 19 mm
55
29,8
35,3
14,0
250
017.417
32 - 21 mm
55
32,0
35,0
14,5
250
017.402
32 - 22 mm
55
32,5
35,3
14,5
260
017.403
32 - 24 mm
55
34,7
35,3
16,5
260
017.404
*
32 - 26 mm
55
36,2
33,2
16,0
290
017.405
32 - 27 mm
55
38,7
33,2
18,0
220
017.416
*
32 - 28 mm
55
40,2
35,3
18,0
230
017.406
*
32 - 29 mm
55
41,2
33,0
18,0
240
017.407
32 - 30 mm
60
42,7
35,2
20,0
290
017.408
32 - 32 mm
60
45,2
35,2
22,0
310
017.415
*
32 - 33 mm
58
47,0
36,2
22,0
380
017.414
32 - 34 mm
58
48,5
36,2
22,0
390
017.409
32 - 36 mm
65
50,0
36,0
24,0
400
017.410
*
32 - 38 mm
65
52,2
36,2
24,0
440
017.411
32 - 41 mm
65
56,7
38,0
27,0
520
017.412
32 - 46 mm
65
62,7
40,2
30,0
620
017.413
32 - 50 mm
65
67,7
40,2
33,0
660
017.418
32 - 55 mm
69
78,5
53,6
35,0
750
017.419
32 - 60 mm
69
84,5
53,6
34,0
850
Código
Ref.
%
L
mm
d1
mm
d2
mm
t
mm
/
017.451
32 - 3/4”
55
29,6
35,0
14,0
250
017.452
32 - 7/8”
55
32,0
35,0
14,5
260
017.453
32 - 15/16”
55
34,0
35,0
16,5
260
017.454
32 - 1”
55
36,0
35,0
16,5
290
017.455
32 - 1.1/16”
55
38,5
33,0
18,0
220
017.456
32 - 1.1/8”
55
40,5
33,0
18,0
240
017.468
32 - 1.3/16”
60
42,5
35,0
20,0
290
017.457
32 - 1.1/4”
60
44,5
35,0
20,0
310
017.458
32 - 1.5/16”
65
46,5
36,0
22,0
380
017.459
32 - 1.3/8”
65
48,0
36,0
22,0
410
017.460
32 - 1.7/16”
65
50,5
36,0
24,0
410
017.461
32 - 1.1/2”
65
52,0
36,0
24,0
440
017.462
32 - 1.5/8”
65
56,5
38,0
27,0
510
017.463
32 - 1.11/16”
65
58,5
38,0
27,0
580
017.464
32 - 1.3/4”
65
60,5
40,0
27,0
620
017.465
32 - 1.13/16”
65
62,5
40,0
30,0
620
017.466
32 - 1.7/8”
65
65,0
40,0
30,0
640
017.467
32 - 2”
65
68,5
40,0
33,0
660
*item não normatizado
D 32
Soquete estriado 3/4”
U23
19 - 60
!
3/4”- 2”
"
DIN 3124, ISO 2725-1
Aço Gedore-Vanadium. Niquelado e cromado. Para trabalhar com
acessórios manuais com encaixe
a
19,05 mm (3/4”), conforme
DIN 3120 - C 20, ISO 1174. Modelo curto.
Código
Ref.
$
L
mm
d1
mm
d2
mm
t
mm
/
017.001
*
D 32 - 19 mm
55
29,6 35,0 14,0
250
017.017
D 32 - 21 mm
55
32,0 35,0 14,5
250
017.002
D 32 - 22 mm
55
32,0 35,0 14,5
260
017.003
D 32 - 24 mm
55
34,5 35,0 16,5
260
017.004
*
D 32 - 26 mm
55
36,0 33,0 16,0
290
017.005
D 32 - 27 mm
55
38,5 33,0 18,0
220
017.016
*
D 32 - 28 mm
55
40,0 33,0 18,0
230
017.006
*
D 32 - 29 mm
55
41,0 33,0 18,0
240
017.007
D 32 - 30 mm
60
42,5 35,0 20,0
290
017.008
D 32 - 32 mm
60
45,0 35,0 22,0
310
017.015
*
D 32 - 33 mm
60
46,8 36,0 22,0
360
017.014
D 32 - 34 mm
60
48,3 36,0 22,0
390
017.009
D 32 - 36 mm
65
50,0 36,0 24,0
400
017.010
*
D 32 - 38 mm
65
52,0 36,0 24,0
440
017.011
D 32 - 41 mm
65
56,5 38,0 27,0
520
017.012
D 32 - 46 mm
65
62,5 40,0 30,0
620
017.013
D 32 - 50 mm
65
67,5 40,0 33,0
660
017.018
D 32 - 55 mm
69
78,0 53,6 35,0
750
017.019
D 32 - 60 mm
69
84,0 53,6 34,0
850
Código
Ref.
%
L
mm
d1
mm
d2
mm
t
mm
/
017.051
D 32 - 3/4”
55
29,6 35,0 14,0
250
017.052
D 32 - 7/8”
55
32,0 35,0 14,5
260
017.053
D 32 - 15/16”
55
34,0 35,0 16,5
260
017.054
D 32 - 1”
55
36,0 35,0 16,5
290
017.055
D 32 - 1.1/16”
55
38,5 33,0 18,0
220
017.056
D 32 - 1.1/8”
55
40,5 33,0 18,0
240
017.068
D 32 - 1.3/16”
60
42,5 35,0 20,0
290
017.057
D 32 - 1.1/4”
60
44,5 35,0 20,0
310
017.058
D 32 - 1.5/16”
65
46,5 36,0 22,0
380
017.059
D 32 - 1.3/8”
65
48,0 36,0 22,0
410
017.060
D 32 - 1.7/16”
65
50,5 36,0 24,0
410
017.061
D 32 - 1.1/2”
65
52,0 36,0 24,0
440
017.062
D 32 - 1.5/8”
65
56,5 38,0 27,0
510
017.063
D 32 - 1.11/16”
65
58,5 38,0 27,0
580
017.064
D 32 - 1.3/4”
65
60,5 40,0 27,0
620
017.065
D 32 - 1.13/16”
65
62,5 40,0 30,0
620
017.066
D 32 - 1.7/8”
65
65,0 40,0 30,0
640
017.067
D 32 - 2”
65
68,5 40,0 33,0
660
*item não normatizado
